| Dimensions(mm) |
1844×1251×1505（L×W×H） |
| Equipment weight（t） |
1.3 |
| Equipment power（Vac,Hz,KW） |
380，50，4 |
| Processing method |
Manual loading and unloading |
| camera type |
Black and white / color linear camera |
| Detection area（mm） |
600×600（MAX） |
| Reference format |
Gerber (RS274X)、ODB++ |
| Check plate thickness（mm） |
0.06 - 2 |
| Minimum line width/distance（μm） |
15 |
25 |
50 |
| Defect confirmation |
VRS Split confirmation |
| Defect scope |
Open circuit, short circuit, gap, convex copper, exposed copper, pinhole, oxidation, scratch, etc. |
| Copper thickness range |
less than 3 oz |
| Testing materials |
Can be used for FR4, FR5, aluminum substrate, reverse copper foil, etc. |
| Temperature and Humidity |
22±2℃，50±10% |
