Horizontal multifunctional sticky board

Technology & products

Horizontal multifunctional sticky board

1. The driven rollers of dry and wet horizontal process equipment are generally difficult to clean. By placing the multi-functional adhesive board as a Dummy board in the horizontal line, it is easy to clean the rollers that are difficult to clean.
2. Placed in an indoor space, it can effectively absorb suspended dust particles in the indoor air.
3. Put it in the oven to absorb dust particles in the circulating air.
4. Can be used as a carrier for soft boards.
5. For temporary storage of electronic parts.

Specifications & Physical Properties

Item Illustrate
Material Fiberglass board + thermoplastic rubber
Viscosity g/25mm 10/15/20
Holding Power g/cm2 1000±50(=Viscosity 15g)
Size mm 510x480/620x535/Customized
Total thickness 0.5/0.8/1.0/1.5/Customized
Color yellow/white/black
Heat resistance temperature °C ~250°C
Acid and alkali resistant PH Acid/weak alkali resistant
Use process Dry process/wet process/oven/SMT reflow oven
